VFFS MULTILANE SERIES

Multilane Stickpack with Multi-Piston Filler

Nichrome's Multilane Stickpack with Multi-Piston Filler is a stick pack pouch packaging machine especially innovated for packing liquids and viscous products in convenient, single-serve stick packs.

For packaging liquids and viscous products such as honey, ketchup, mayonnaise, mustard paste, jam, shampoo, etc., Nichrome's STICKPACK offers a stainless steel structure, pneumatically operated piston filler and longitudinal & cross-sealing jaw assemblies suitable for laminates. A CE certified PLC controller makes it easy to operate.

Applications

Mayonnaise, Mustard Paste, Jam, Water, Shampoo

Honey

Ghee

Ketchup

Olive Oil

POUCH FORMAT

Center Seal Stickpack

Center Seal Stick with V notch

Technical Specifications

Pack Style /format	Centre Seal Stickpack
No. of lanes	3, 4, 5, 6 lanes
Quantity	5 ml ~ 30 ml
Capacity	90 ~ 240 sticks/min
Packing Material	Heat sealable laminate films.
Pack Size Range	30 ~ 35 W (fixed/dedicated) & 50 ~ 170 mm L (Adjustable)
Maximum Roll Width	480 mm max
Maximum Roll Diameter	400 mm
Air consumption	6 bar, 300 litres/min
Electrical Supply	Stabilised 415 VAC, 3 phase, 4 wire, 50 Hz, 3 KWH
Overall Machine dimension	1350 mm W x 1700 mm D x 2230 mm H
Weight of the machine ( approx.)	500kg

Food

Pharma

Non Food
